Key Features Model: IPC3613LB-AF28K-G Image: 1/2.7", 3.0 megapixel, progressive scan, CMOS Sensor Smart IR, up to 30m (98ft) IR distance Built-in-Mic PoE Supported
| Camera Feature | ||
| Image Sensor | 1/2.7", 3.0 megapixel, progressive scan, CMOS | |
| IR Distance | Smart IR, up to 30m (98ft) IR distance | |
| Others | Minimum Illumination: Colour: 0.01Lux ( F2.0, AGC ON) 0Lux with IR Shutter: Auto/Manual, 1 ~ 1/100000s Material: Metal+Plastic | |
| Lens | ||
| Type | 2.8mm and 4.0mm @2.0, Fixed-focal | |
| Focal Length | 850nm | |
| Aperture | Build-in-Mic | |
| Angle of View | 112.9° x 59.1° x 121.2° (H x V x D) | |
| Others | Lens Mount: M12 IR Distance: Up to 30m (98ft) IR range IR Control: Auto/Manual Flip: Normal/ Vertical/ Horizontal/ 180°/ 90°Clockwise/ 90°Anti-clockwise Digital Noice Reduction: 2D/ 3D DNR | |
| Physical Specification | ||
| Dimension | Φ118 x 96mm (Φ4.6” x 3.8”) | |
| Weight | 0.30kg (0.86lb) | |
| Power | DC 12V±25%, PoE (IEEE 802.3af) Power consumption: Max 7.0W | |
| Interface | Power Interface: Ø 5.5mm coaxial power plug Network Interface: 1 * RJ45 10M/100M Base-TX Ethernet | |
| Others | Working Environment: -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) Water & Dust Protection: IP67 Reset Button: N/A Surge Protection: 4KV Network Storage: ANR, NAS(NFS) Defog: Digital Defog | |
| Warranty | ||
| Warranty | 1 Year Warranty | |
The Uniview IPC3613LB-AF28K-G 3MP HD IR Fixed Eyeball IP Camera is designed for indoor and outdoor use. The Uniview Camera Powered with a 3MP CMOS sensor, produces high-quality 2304x1296 resolution at 30/25fps captures. The Uniview IPC3613LB-AF28K-G Network Camera Compression Format Ultra 265/H.265/H.264/MJPEG.With built-in smart infrared (IR) technology, this IP camera offers up to 30 meters of night vision, which is perfect for areas with low ambient light. This IPC3613LB-AF28K-G Camera uses an audio recording microphone to add an extra layer of security. The Uniview IPC3613LB-AF28K-G Security camera is dustproof and waterproof, with an IP67 rating. The Night Vision camera also supports Power over Ethernet (PoE) for simplified installation and less cable messes. This 3MP HD IR Fixed Eyeball IP Camera is also given a 3-axis adjustment structure that allows us to flexibly install and achieve the best field of view. With network protocols like ONVIF support, the Uniview IPC3613LB-AF28K-G can easily integrate into existing security systems. This Uniview IPC3613LB-AF28K-G 3MP HD IR Fixed Eyeball IP Camera does very well for home or corporate use related to security and clear imaging hence it doesn't need to be anything else for use regarding surveillance.
